PV String Input
Max. Continuous PV Input Power: 20kW
Max. DC Voltage: 1100V
Nominal Voltage: 720V
MPPT Voltage Range: 140V-1000V
MPPT Range (Full Load): 420V-850V
Start Voltage: 130V
MPPT Tracker / Strings: 2/2
Max. Input Current Per MPPT: 15A
Max. Short-circuit Current Per MPPT: 20A

AC Output (Grid)
Nominal AC Output Power: 10kW
Max. AC Apparent Power: 11kVA
Nominal AC Voltage: 400Vac 3W+N+PE
AC Grid Frequency Range: 50 / 60Hz
Max. Output Current: 14.5A
Max. Input Current: 16A
Power Factor (cosF ): 0.8leading-0.8lagging

Battery Input
Battery Type: LFP (LiFePO4)
Nominal Battery Voltage: 48V
Charging Voltage Range: 40-60V
Max. Charging Current: 200A
Max. Discharging Current: 200A

AC Output (Backup)
Max. Output Apparent Power: 10kVA
Rated Output Power: 9.2kVW
Rated/Max. Output Current: 14.5A/16A
Nominal Output Voltage: 400V
Nominal Output Frequency: 50/60Hz
Output THDv (@Linear Load): <3%(Linear Load)

Protection
Anti-islanding Protection: Yes
Output Over Current: Yes
DC Reverse Polarity Protection: Yes
String Fault Detection: Yes
AC/DC Surge Protection: DC Type II;AC Type III
Insulation Detection: Yes
AC Short Circuit Protection: Yes

General Specifications
Dimensions W x H x D: 540*980*240mm
Weight: 42kg
Operating Temperature Range: -25°C~+60°C
Noise (dB): <25
Cooling Type: Natural Convection
Max. Operation Altitude: 3000m (Derating > 2000m)
Operation Humidity: 0~95% (No Condensation)
IP Class: IP65
Topology: Battery Isolation
Communication: RS485/CAN2.0/WIFI/4G
Display: LCD/APP
