The WX Infinity (WXI) series is the first in the Infinity range to have a 180 degree detection area. Using both analog and digital technologies, the WXI series excels at detecting intrusions before they enter your protected area. The WX Infinity series features individual left/right alarm outputs, sensitivity adjustments and area size adjustments, where the detection distance can be easily adjusted between 2.5 and 12 meters independently.

The WXI series is also equipped with SMDA (Super Multi-Dimensional Analysis) logic, which dramatically improves immunity against changes in temperature or the movement of trees and vegetation, effectively distinguishing between the cause of false alarms and intrusions. real.

With its wide 180-degree field of view and capabilities to adapt its configuration to your facility environment, the WX Infinity Series will provide an effective solution for new and existing security systems.

Characteristic

180° panoramic wired PIR detector for outdoor use
Antimasking by active LED
Detection Method: Passive Infrared
180° coverage angle
14 pairs of horizontal detection zones and 2 vertical layers
Adjustable range between 2.5 and 12 meters
Detection speed from 0.3 to 2 m/s
Left/right detection range independently adjustable in 5 levels
Adjustable sensitivity in 3 levels
Self-learning of the IR digital anti-masking function
SMDA Advanced Processing Logic
Mounting height of 0.8 ~ 1.2 meters
Left alarm relay: NC/NO (28V DC, 0.1A)
Right alarm relay: NC/NO (28V DC, 0.1A)
Fault output: NC (28V DC, 0.1A)
Tamper output: NC (28V DC, 0.1A)
Power: 9.5V ~ 18V DC /23mA at 12V
Operating temperature -30°C ~ +60°C
Relative humidity up to 95%
Degree of protection IP55
Wall or pole mount
Dimensions: 200 (H) x 81.5 (W) x 81.2 (D) mm
Weight: 440g
