4-megapixel 1/2.8" CMOS image sensor
Smart H.265+, Smart H.264+, H.265, H.264 and MJPEG video compression
Resolution: 4MP (2560x1440), 3MP (2304x1296), 1080P (1920x1080), 1.3MP (1280x960), 720P (1280x720), D1 (704x576, 704x480), VGA (640x480), CIF (352x288, 352x240)
Stream 1: 4MP, 3MP, 1080P, 1.3MP, 720P (1~25/30 ips)
Stream 2: D1, CIF, VGA (1~25/30 fps)
Stream 3: 720P (1~25/30 ips)
Day/night mode with removable mechanical filter
0.005 lux F1.6 (color), 0.0005 lux F1.6 (B/W), 0 lux IR On
Smart Dual Light: 2 IR LEDs (up to 50 m) + 2 warm white LEDs (up to 30 m)
5X optical zoom: 2.7 ~ 13.5 mm
Angle of view: 94.9°~30.1°(H), 51°~17.1°(V), 112.3°~34.6°(D)
Auto, semi-automatic and manual focus control
Fixed iris control
16X digital zoom
Image modes: BLC, HLC, WDR 120dB, 2D/3D-NR, EIS, digital Defog
White balance with 8 modes
Automatic and manual gain control
Supports videosensor and ROI (Regions of Interest)
Perimeter protection with line crossing detection, intrusion detection (with person/vehicle classification), fence crossing detection, loitering detection, intrusion detection (with person/vehicle classification), fence crossing detection, loitering detection, intrusion detectionloitering detection, abandoned/lost object detection, fast motion detection, parking detection, people gathering detection, etc.
Face detection and SMD
LITE autotracking available
Horizontal positioner: 0° ~ 355°.
Vertical positioner: -15° ~ 90°.
Manual speed: 0.1° ~ 36°/sec (H), 0.1° ~ 25.8°/sec (V)
Preset speed: 35.7°/sec (H), 27.1°/sec (V)
300 presets
Built-in microphone and speaker
1 audio input / 1 audio output
Built-in active deterrent with blue/red flashing light, siren and alarm output
1 alarm input / 1 alarm output
MicroSD card slot up to 512GB (card not included)
Network interface: RJ45 (10/100 Base-T)
Network protocols: FTP, RTMP, IPv6, Bonjour, IPv4, DNS, RTCP, PPPoE, NTP, RTP, 802.1x, HTTPS, SNMP, TCP/IP, DDNS, UPnP, NFS, ICMP, UDP, IGMP, SMB, HTTP, SSL, DHCP, SMTP, Qos, RTSP, ARP
Interoperability: ONVIF (S/G/T), CGI, SDK, P2P
Compatible with IE, Chrome, Firefox and Safari browsers
Compatible with IOS and Android devices
Up to 20 users
DMSS, DSS Pro management software
Power: 12V DC, 2A (±10%) / PoE+ (802.3at)
Power consumption: 4.5W (basic), 15W (maximum)
Operating temperature from -30°C ~ +60°C
Relative humidity =95%.
IP66 degree of protection
Lightning-proof 6KV
Dimensions: 140 (W) x 236,1 (H) x 142,6 mm
Net weight: 1.5 kg
Gross weight: 2.1 kg
Includes wall bracket
No power supply included
