4 megapixel 1/2.9" CMOS sensor
Compression formats: Smart H.265+, Smart H.264+, H.265, H.264, MJPEG
Digital resolution: 4MP (2688x1520), 3.6MP (2560x1440), 3MP (2304x1296), 1080P (1920x1080), 1.3MP (1280x960), 720P (1280x720), D1 (704x576), VGA (640x480), CIF (352x288)
Stream 1: 4MP (1~20 fps), 3.6MP (1~25/30 fps)
Stream 2: D1 (1~25/30 fps)
Day/night mode with removable mechanical filter
Smart Light: 1 IR led + 1 warm light led,30 meters range
0.006 lux F1.6 (color), 0.0006 lux F1.6 (B/W), 0 lux IR On
2.8 mm fixed optics
Angle of view: 95°(H), 52°(V), 114°(D)
Imaging modes: BLC, HLC, WDR 120dB, 3D-NR, Mirror.
White balance with 6 modes
Automatic and manual gain control
Supports 4-zone videosensor, 4 regions of interest (ROI) and 4-zone privacy masking
Perimeter protection with cross-line detection and intrusion detection (both modes support human/vehicle classification)
SMD Plus
Built-in microphone
MicroSD card slot up to 256GB (not included)
Network interface: RJ45 (10/100 Base-T)
Network protocols: IPv4, IPv6, HTTP, TCP, UDP, ARP, RTP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, NTP, Multicast, ICMP, IGMP
ONVIF (Profile S/T), CGI, P2P, Milestone, SDK and API support
Up to 6 users
Remote viewing via IE, Chrome and Firefox browsers
DSS, DMSS management software
Compatible with IOS and Android mobile devices
Power supply: 12V DC / PoE (802.3af)
Power consumption: 4.4W (12V) / 5.2W (PoE)
Storage temperature from -40°C ~ +60°C
Operating temperature from -40°C ~ +60°C
Relative humidity: =95%.
IP67 degree of protection
Metal housing
Dimensions: 70 (W) x 70 (H) x 166.2 mm
Net weight: 480 g
Gross weight: 590 g
3AXIS: 0°~360°(PAN), 0°~90°(TILT), 0°~360°(Rotation)
