1/2.7" 8 megapixel CMOS sensor
Compression formats: Smart H.265+, Smart H.264+, H.265, H.264, MJPEG
Digital resolution: 8MP (3840x2160), 6MP (3072x2048), 5MP (3072x1728), 5MP (2880x1620), 4MP (2688x1520), 3MP (2048x1536), 3MP (2304x1296), 1080P (1920x1080), 1.3MP (1280x960), 720P (1280x720), D1 (704x576), VGA (640x480), CIF (352x288)
Stream 1: 8MP (1~20 fps), 4MP (1~25/30 fps)
Stream 2: D1 (1~25/30 ips)
Day/night mode with removable mechanical filter
Smart Light: 2 IR leds (60 meters) + 2 warm light leds (50 meters)
0.008 lux F1.6 (color), 0.0008 lux F1.6 (B/W), 0 lux IR On
3.6 mm fixed optics
Angle of view: 87°(H), 49°(V), 100°(D)
Imaging modes: BLC, HLC, WDR 120dB, 3D-NR, Mirror.
White balance with 6 modes
Automatic and manual gain control
Supports 4-zone videosensor, 4 regions of interest (ROI) and 4-zone privacy mask
Perimeter protection with cross-line detection and intrusion detection (both modes support human/vehicle classification)
SMD Plus
Built-in microphone
1 audio input / 1 audio output
1 alarm input / 1 alarm output
MicroSD card slot up to 256GB (not included)
Network interface: RJ45 (10/100 Base-T)
Network protocols: IPv4, IPv6, HTTP, TCP, UDP, ARP, RTP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, QoS, UPnP, NTP, Multicast, ICMP, IGMP, NFS, PPPoE, Boujour, P2P
ONVIF (Profile S/T/G), CGI, SDK and API support
Up to 20 users
Remote viewing via IE, Chrome and Firefox browsers
SmartPSS Lite, DSS, DMSS management software
Compatible with IOS and Android mobile devices
Power supply: 12V DC / PoE (802.3af)
Consumption: 7W (12V) / 8.3W (PoE)
Storage temperature from -40°C ~ +60°C
Operating temperature from -40°C ~ +60°C
Relative humidity: =95%.
IP67 protection rating
Metal housing
Dimensions: 90.7 (W) x 90.7 (H) x 238.5 mm (W) x 90.7 (H) x 238.5 mm (2.5 x 2.8 in)
Net weight: 720 g
Gross weight: 970 g
3AXIS: 0°~360°(PAN), 0°~90°(TILT), 0°~360°(Rotation)
