4 IP channels
Video compression: Smart H.265+, H.265, Smart H.264+, H.264, MJPEG
Simultaneous video outputs HDMI (4K) and VGA (1080P)
Display division: 1, 4
1 input / 1 output RCA audio
Audio compression: PCM, G.711a, G.711u, G726
Recording resolution: 12MP, 8MP, 5MP, 4MP, 3MP, 1080P, 720P, D1
Bandwidth: 80 Mbps access, 80 Mbps record, 60 Mbps send
Decoding capacity with AI off: 1 channel at 12MP (30 ips), 1 channel at 8MP (30 ips), 2 channels at 5MP (30 ips), 3 channels at 4MP (30 ips), 6 channels 1080P (30 ips)
AI enabled decoding capability: 1 channel at 8MP (30 fps), 1 channel at 5MP (30 fps), 2 channels at 4MP (30 fps), 4 channels 1080P (30 fps)
Manual recording modes, alarm recording, motion detection recording, scheduled recording.
AI on recorder:
1-channel perimeter protection
Face detection with 1-channel attributes and up to 12 frames per second per channel
Face recognition with 1-channel attributes, up to 4 images per second and up to 10 databases with 5000 images
SMD Plus up to 4 channels with filtering between people and vehicles
AI support from compatible IP cameras:
Supports up to 4 IP cameras with perimeter protection.
Supports up to 5 IP cameras with face detection
Support up to 5 IP cameras with face recognition
Supports up to 6 IP cameras with SMD Plus
Up to 4-channel playback
