Detectors technical characteristics
Two-way wireless technology Yes
Blue Wave technology Yes
Automatic sensitivity Yes
Digital temperature compensation Yes
Tamper protection Front and rear
Separate LED indication Microwave, PIR, Alarm
Signal Strength Indicators (SSI) Yes
3 microwave frequencies to avoid interference Yes
Detectors technical characteristics
Signal Strength Indicators (SSI) Yes
Instant two way device control (ITDC) Yes
Pyronix high security two way wireless data encryption protocol (TDE) Yes
Pyronix intelligent jamming detection Yes
868MHz transceiver FM technology Yes
One push to learn Yes
Tranmission method Fully encrypted rolling code
Transmission range 1.6km in open space
Detectors technical characteristics
Maximum range 10m
Dual technology Yes
Animal immunity 25kg
Detection speed 0.3- 3.0m/s
Detection zones 52
Detection planes 5
Mounting
Wall mounted Optional brackets available
Ceiling mounted Optional brackets available
Optimum coverage height 1.8 - 2.4m
Certified mounting height 2.4m
Environmental and operating features
Storage temperature -20C to 50C
Certified operating temperature -10C to 40C
Nominal operating temperature -10C to 50C
Physical dimensions (H x W x D) 117 x 69 x 59mm
Electrical & battery
Battery type 2 x 3.0V CR123A
Battery life Up to 2 years
Battery voltage 3.0V
Certifications and warranty
Electrical conformity CE
EN Certificate EN50131-2-4:2008, EN50131-5-3:2005+A1:2008, PD6662:2010
Certification type IMQ
Certificate number CA12.01484
Environmental class II
Warranty 2 years
Security Grade Grade 2
